Removal and Replacement Procedures
Maintenance and Service Guide 5–59
5.17 Fan/Heat Sink Assembly
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini Card module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.11)
f. Display assembly (Section 5.12)
g. Base enclosure (Section 5.13)
h. System board (Section 5.14)
Fan/Heat Sink Assembly Spare Part Number Information
Fan assembly (includes thermal paste) 410055-001
Heat sink assembly (includes thermal paste) 409073-001
