Product Description
Maintenance and Service Guide 1–17
The external components on the bottom of the computer are
shown below and described in Table 1-8.
Bottom Components
Table 1-8
Bottom Components
Item Component Function
1 Battery bay Holds the battery.
2 Battery release latch Releases a battery from the battery bay.
3 Labels area Contains the serial number and other
information labels.
4 Optical drive Reads an optical disc.
