5–22 Maintenance and Service Guide
Removal and Replacement Procedures
3. Turn the computer display-side up with the front toward you.
4. Open the computer as far as possible.
5. Insert a flat-bladed tool into the switch cover notches behind
the
f1, f5, f11, and insert keys 1 and lift up until the switch
cover 2 disengages from the computer.
6. Remove the switch cover.
Removing the Switch Cover
Reverse the above procedure to install the switch cover.
