Removal and Replacement Procedures
Maintenance and Service Guide 5–35
17. Remove the four Phillips PM2.5×5.0 screws 1 that secure
the display panel and inverter board to the display enclosure.
18. Remove the display panel 2 and inverter board 3.
Removing the Display Panel and Inverter Board
Display Assembly Subcomponents
Spare Part Number Information
15.4-inch, WXGA with BrightView Display Panel Kit
(includes display panel cable)
435787-001
Display inverter board 407800-001
