5–62 Maintenance and Service Guide
Removal and Replacement Procedures
7. Remove the two Phillips PM3.0×6.0 screws on each side of
the external monitor port that secure the fan/heat sink
assembly to the system board.
Removing the Fan/Heat Sink Assembly Screws, Part 3
