HP Compaq Presario,Presario C300

A–26 Maintenance and Service Guide
Screw Listing
Phillips PM3.0×6.0 Screw Locations
Table A-10
Phillips PM3.0×6.0 Screw
Color Qty. Length Thread
Head
Width
Black 2 6.0 mm 3.0 mm 4.0 mm
Where used:
2 screws that secure the fan/heat sink assembly to the system board
(documented in Section 5.17)
mm
