HP COMPAQ PRO 6300

SFF MT
Storage Drive Support
SFF MT
MCR ODD HDD MCR ODD HDD
# of supported
devices
1 1 2 1 2 2
Drive position 1 2 1,3 3 1,2 4,5
Controller
Hard Drive Controller These systems provide four serial ATA (SATA) interfaces that support transfer rates up to 6.0
Gb/s (for ports 0 and 1, 3 Gb/s on all others). These systems can also support an external SATA
(eSATA) device through an optional bracket/cable assembly.
SATA Interfaces 1 ea. SATA 3.0
1 ea. SATA 2.0
1 ea. eSATA
Host SATA Controller Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description
of the hardware/software interface between system software and the host controller hardware.
QuickSpecs
HP Compaq Pro 6300 Business PC
Technical Specifications – Hard Disk and Solid State Storage
DA - 14269 North America — Version 40 — December 13, 2013 Page 27
