HP Compaq ProLiant DL360 Generation 2 - Controller and Network Interface Specifications; Smart Array 5 i Controller Specifications; Network Interface Card Specifications

Smart Array 5i Controller
(integrated on system
board)
Protocol Wide Ultra3 SCSI
Processor 32-bit RISC
XOR engine Hardware RAID
Electrical interface Low Voltage Differential (LVD)
Simultaneous Drive
Transfer Channels
2
Channel Transfer Rate 320 MB/s total; 160 MB/s per channel
SCSI Port Connectors One external and one internal SCSI port
NOTE: The ProLiant DL360 Generation 2 (G2) does not offer an
external SCSI port.
Memory 32 MB of DRAM used for code, transfer buffers, and non-battery-
backed read cache
Peak transfer rate 160 MB/s
Logical Drives
Supported
32
Software Upgradeable
Firmware
YES
RAID Support RAID 5 (Distributed Data Guarding)
NOTE: A minimum of 3 hard drives are required for RAID 5 and only 2
are supported on the ProLiant DL360 Generation 2 (G2). Therefore
RAID 5 is not supported on the ProLiant DL360 Generation 2 (G2).
RAID 1+0 (Striping and Mirroring)
RAID 1 (Mirroring)
RAID 0 (Stripping)
Disk Drive and
Enclosure Protocol
Support
Ultra2 and Ultra3
Two Compaq NC7780
PCI-X 10/100/1000-T
Server Adapters
Network Interface 10/100/1000-T
Compatibility EEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 80.3u 100Base-TX
Data Transfer Method 64-bit/66MHz PCI-X
Network Transfer
Rate
10Base-T (Half-Duplex),
10Base-2
10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
1000Base-TX 1000 Mb/s
Connector RJ-45
Cable Support 10Base-T Categories 3, 4 or 5 UTP
up to 328 ft (100 m)
100Base-TX Category 5 UTP up to 328 ft (100 m)
QuickSpecs
Compaq ProLiant DL360 Generation 2
TechSpecs
DA - 11049 Worldwide QuickSpecs — Version 35 — 9.30.2003 Page 42
