6–8 Maintenance and Service Guide
Removal and Replacement Procedures
2. Remove the two PM2.0×5.0 screws 1 that secure the hard
drive cover to the tablet PC.
3. Lift the right side of the hard drive cover and swing it to the
left 2 to remove it.
✎
The hard drive cover is included in the Miscellaneous
Plastics/Hardware Kit, spare part number 383549-001.
Removing the Hard Drive Cover
To Next Page
