5–5
6
Maintenance and S
ervi
ce Guide
Re
mo
val and R
eplacement Pr
ocedure
s
2.
Disconnect the Bluetooth module cable
1
from the system
board and remov
e the cable.
3.
Remov
e the four T
orx8 T8M2.0×5.0 screws
1
that secure the
system board to the computer
.
R
emo
v
ing the S
ys
tem Boar
d Sc
r
e
w
s
, P
art 1
138
140
