Maintenance and Serv
ice Gui
de
5–9
4.
Loosen the Phillips PM2.5×13.0 hard dri
v
e retention
scre
w
1
.
5.
Grasp the mylar tab
2
on the hard dri
v
e and slide the hard
dri
v
e to the right
3
to disconnect it from the system board.
6.
Remov
e the hard dri
ve
4
.
R
emo
v
ing the Har
d Dr
i
v
e
91
93
