Page 25
HP S7500/MV7500/CV7500
No. Location Part Number Description
24 Q419 6422006000 TR NPN 2SD2012 TO-220(IS)
25
Q420 Q421
Q430
6426010510 (S0)
6426010500 (S1)
FET N-CHNL IRF630MFP/IRFS630A
26 Q451 6426006300 FET N-CHNL IRFS634A FAIRCH 11d
27 R803 6203080022 POSISTOR & OHM DGC2D8ROM
28 R804 6201100012 THERMISTOR 10 OHM 3A P=5 UEI
29 R802 R803 6221127852 MOF OHM 0.27 1W J HOR
30 T401 6135000801 XFRMER HOR DRIVE THD-1008A EI19
31 T402
6133070230
6133070240
FBT TFB-7023 FEA9 SAMPO (S1)
FBT TFB-7024 CF2001 LIEN CHANG (S0)
32 T403 6136001800 XFRMER DYNAMIC TDF-1018 EI19LSE
33 T801 6138001603 LINE FILTER TLF-1016C 16mH LSE
34 T802
6131042221
6131042231
XFRMER PWR TPW-1084A ERL35 LSE (S0)
XFRMER PWR TPW-1084A ERL35 HJC (S1)
35 X701
6449006900 (S1)
6449006910 (S0)
CRYSTAL 12.000 MHZ 49U 30PF TOP
