Page 5
HP S7500/MV7500/CV7500
2 Product Specifications
2-1 Specifications
Note: Above specifications are subject to change without prior notice.
Picture Tube
17-inch (16-inch Visual image area), sloted mask, 90 degrees
deflection, dot type black matrix, medium short persistence
phosphor, dark tint, non-glare/ anti-static screen,
0.27 mm dot pitch for E1770NSL/T and 0.25mm dot pitch for HP
S7500/MV7500/CV7500
Scanning Frequency
VGA, Super VGA, 1024x768@60/70/75/85 Hz
1280x1024@60Hz
Maximum Resolution 1280 dots (H) x 1024 lines (V) @60Hz refresh rate
Display Area 306 mm (H) x 230 mm (V) typical
Display Characters 80 char. x 60 rows on a 10 x 10 matrix
Display Colors Analog
Input
Unlimited Colors
Synchronizatin Signals Separate Sync: horizontal/vertical, TTL, positive or negative
Synchronization
Frequencies
Horizontal : 30 to 70 kHz
Vertical : 50 to 140 Hz
Signal Connectors 15-pin, D-shell connector
Video Signals Analog : 0.7 Vp-p, RGB positive
Power Input 75 Watts (maximum) AC rated voltage, 100VAC to 240VAC
Misconvergence Center Area : < 0.3 mm; Corner Area : < 0.4mm
User Controls Power On/Off, Contrast, Brightness, Horizontal Size, Horizontal
Position, Vertical Size, Vertical Position, Pincushion, Trapezoid,
Rotation, Color temperature, Language, Display Frequency,
Degauss, Recall, H. Moire,
V. Moire
Service Controls PWB-1709
PWB-1707 : power voltage adjust (VR801)
Preset Modes 8 (see Table 2-2. Timing Chart)
Environmental
Considerations
Operation temperature : 10
o
C to 40
o
C ambient
Operation Humidity : 20% to 80% ambient
Storage temperature : -40
o
C to 65
o
C ambient
Storage Humidity : 10% to 90% (non-condensing)
Altitude : Non operating 40,000 feet sea level
operating 10,000 feet sea level
