Page 24
HP S7500/MV7500/CV7500
6 Recommended Parts List
Note:1. The components identified by “ “ mark are critical for X-ray safety. Replace these with
exactly the same parts specified.
2 . There is only OTP IC at the model beginning (FPR stage or before). When it put in mass
production and there must be Mask coming out. If you have spart parts need, please use BOM
to get the last release part number and related information.
No. Location Part Number Description
1 Q401 6421002705 TR NPN KSD1616A G TA
2 C808 6312615109 ALU uF 150 400V F 85C 25x35
3
D801 D802
D803 D804
6412025607 DIODE LT2A06 T52 2A/800V
4 D814
6412020022 (S0)
6412021702 (S1)
DIODE FE30-02BXF06
5 D810 6412004117 DIODE UF2004M 2A/200V 50 nS
6 D815 6412002617 DIODE UF3002M 3A/100V 50 nS
7 D817 6412024404 DIODE HER106 1A/600V 50 nS
8 F801 6851504053 FUSE TIME LAG H-BRK 4A/250V
9 I301 6442026401 IC TDA4863AJ 7P (PHILIPS)
10 I401 6442030000 IC TDA4841 32P SDIP (PHILIPS)
11 I501 6442031503 IC LM1237 24P SDIP (NS)
12 I502 6442034900 IC LM2466 9P NS
13 I503 6442029901 IC LM2480 8P NS
14 I701 6448017800(OTP) IC NT6865 42P PDIP NOVA
15 I703 6448015730 IC MTV24C08 (ATC)
16 I705 6442000875 IC KIA78L05 (SAMSUNG)
17 I801 6442031600 IC 5S 0765C 5P FAIRCH
18 L404 6111274130 COIL CHOKE 2.7mH K DR8x10
19 L405 6119008400 COIL LINEAR
20 L409 6111155133 COIL CHOKE 150uH DRWW 14x15 LY3B
21 L410 6111155138 COIL CHOKR L=150uH K DRWW 14x15
22 Q402 6421004900 TR NPN 2SC5387
23 Q405 6422002925 TR NPN HBF422T/B TO-92 TAPING
To Next Page
