Technical Specifications
Technical Specifications
1. Use the standard image sizes to avoid distortion of the displayed image.
PICTURE TUBE
Size 15-inch flat screen / 13.9-inch viewable image
Phosphorous Red, Green, Blue medium short persistence
Dot pitch 0.28 mm dot pitch
Face Plate Anti-glare, multilayer, anti-static coating
INPUT SIGNAL
Video 0.66 Vp-p analog RGB
Synchronization Separated H/V (TTL level), H/V mixed (TTL level)
INTERFACE
Input Connectors 15-pin mini D-SUB
SCANNING FREQUENCY
Horizontal 30 to 69 kHz
Vertical 50 to 160 Hz
MAX. RESOLUTION (H
×
V)
1280
×
1024 at 60 Hz refresh rate
WARM-UP TIME
30 minutes to reach optimum performance level
PIXEL CLOCK
110 MHz Maximum
IMAGE SIZE
Standard size
1
: 267 (H)
×
200 (V) mm (resolution at 1024
×
768, aspect ratio 4:3)
250 (H)
×
200 (V) mm (resolution at 1280
×
1024, aspect ratio 5:4)
Maximum size: 282.5 (H)
×
212 (V) mm
POWER SOURCE
AC 90 to 264 V, 47 to 63 Hz, 80 W (max), less than 15 W in stand-by mode, less than 5 W in sleep mode
OPERATING ENVIRONMENT
Temperature 0
°
C to 40
°
C (operating)
- 20
°
C to +70
°
C (storage)
Humidity 10% RH through 80% (without condensation) (operating)
5% RH through 95% (without condensation) (storage)
CABINET DIMENSIONS
387 (H)
×
376 (W)
×
427 (D) mm
WEIGHT
13.6 kg
TILT/SWIVEL STAND
Tilt Angle - 5
°
to +10
°
Swivel Angle
±
45
°
