Interfaces
InterfacesInterfaces
Interfaces Ultra-Slim Desktop
Ultra-Slim DesktopUltra-Slim Desktop
Ultra-Slim Desktop Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Serial Port 1 optional 1 standard, 2nd via option 1 standard, 2nd via option
Parallel Port 1 optional 1 1
PS/2 1 Keyboard and 1 Mouse
USB (2.0) 8 ports (6 rear/2 front)
RJ-45 10/100/1000 Network X
Keyboard X (PS/2)
Mouse X (PS/2)
Multibay 1 standard optional optional
Video (VGA) X
Audio X
Power Supply
Power SupplyPower Supply
Power Supply Ultra-Slim Desktop
Ultra-Slim DesktopUltra-Slim Desktop
Ultra-Slim Desktop Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Power Supply 200 watt custom power supply -
Active PFC)
240 watt custom power supply -
Active PFC)
340 watt custom power supply -
Active PFC)
Operating Voltage Range 90 - 132/180 - 264 VAC 90 - 132/180 - 264 VAC 90 - 132/180 - 264 VAC
Rated Voltage Range 100 - 127/200-240 VAC 100 - 127/200-240 VAC 100 - 127/200-240 VAC
Rated Line Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range 47 - 63 Hz 47 - 63 Hz 47 - 63 Hz
Rated Input Current 5A/2.5A 5A/2.5A 6A/3A
Heat Dissipation Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1050 btu/hr
(265 kg-cal/hr)
Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1260 btu/hr
(318 kg-cal/hr
Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1575 btu/hr
(397 kg-cal/hr)
Power Supply Fan 70mm variable speed 80mm variable speed 92mm variable speed
Energy Star Compliant X X X
Blue Angel Compliant (<5w in
S5-- Power Off)
X X X
FEMP Standby Power Compliant
(<2W in S5 - Power Off)
X X X
Power Consumption in ES Mode
- Suspend to RAM (S3) (Instantly
Available PC)
2.5W to 3W 2.5W to 3W 2.5W to 3W
Processor/Cache Memory Power
-Down (S3)
< 3W < 3W < 3W
Environmental and Mechanical
Engineering Support Center
(EMESC) - Intranet Web Site only
http://env-webserver.ccm.cpqcorp.net/EMESC/default.htm
QuickSpecs
HP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 SeriesHP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 Series
Technical Specifications
DA - 11948 North America — Version 33 — January 31, 2006 Page 20

HP dc7100 Specifications

General

Processor Speed	Up to 3.8 GHz
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Processor	Intel Pentium 4
Chipset	Intel 915G Express
Graphics	Integrated Intel Graphics Media Accelerator 900
Storage	Up to 250 GB SATA HDD
Optical Drive	CD-ROM, DVD-ROM, CD-RW, DVD+RW
Network	Integrated Gigabit Ethernet
Form Factor	Small Form Factor
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, serial, parallel, PS/2, VGA
Operating System	Windows XP Professional
