Serviceability Features of
Serviceability Features ofServiceability Features of
Serviceability Features of
System
SystemSystem
System
Description
DescriptionDescription
Description
Ultra-slim
Ultra-slimUltra-slim
Ultra-slim
Desktop
DesktopDesktop
Desktop
Small Form
Small FormSmall Form
Small Form
Factor
FactorFactor
Factor
Convertible
ConvertibleConvertible
Convertible
Minitower
MinitowerMinitower
Minitower
Dual Color Power LED on
Front of Computer
(Indicates Normal
Operations and Fault
Conditions)
--
X X X
Diagnostic LED
Explanation Table
Number of 1-second red LED blinks followed by 2-second
pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
X X X
System/Emergency ROM
Recovers corrupted system BIOS.
X X X
Flash Recovery with Video
Configuration Record SW
--
X X X
Over-Temp Warning on
Screen (Requires IM
Agents)
--
X X X
OS CD (Restore OS CD)
Restores computer to its original factory shipping image
X X X
Restore CD
Restores the computer to its original factory shipping image
X X X
Flash ROM
--
X X X
5 Aux Power LED on
System PCA
--
X X X
Dual Function 5V Aux
Power LED (ON)/PS_ON
LED (OFF) on System PCA
--
X X X
Diagnostic Power Switch
LED on board
--
X X X
Clear Password Jumper
--
X X X
Clear CMOS Button
--
X X X
CMOS Battery Holder for
easy Replacement
--
X X X
Processor ZIP Socket for
easy Upgrade
--
X X X
DIMM Connectors for easy
Upgrade
--
X X X
NIC LEDs (integrated)
(Green & Amber)
Used to determine NIC status
X X X
QuickSpecs
HP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 SeriesHP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 Series
Technical Specifications
DA - 11948 North America — Version 33 — January 31, 2006
Page 26
