hp designjet 120/120nr and 130/130nr printer service manual

Cover Assemblies (Applicable to DesignJet 130/130nr)

Cover Assemblies

Reference

Drawing

HP Part Number Quantity Description/Comments

1C7791-603001Left Cover

2 0515-2811 2 Screw

3 C7791-60286 1 Right Cover

4 0515-2812 2 Screw

5 C7790-60295 1 Filter Assembly

6 C7791-60285 1 Back Cover (Center Cover)

7 0515-2811 6 Screw

8 C7790-60119 1 Door Sensor Assembly

9 C7791-60294 1 Ink Cartridge Door (HP DesignJet 130)

C7791-60295 1 Ink Cartridge Door (HP DesignJet 130nr)

10 C7790-60457 1

Printhead Door Assembly (includes Ink

Cartridge Door Hinge)

11 C7791-60277 1 Access Door Assembly

12 C7791-60216 1 Rear Trim Kit (Applicable to DesignJet 130)
