Correct
Incorrect
If the line is not perfectly straight at bias 0 in the test image (see figure above), try
the following:
1 Perform the Accuracy Calibration (see page 6–11) and print the Print Quality Test
Print again to see if there has been any improvement.
2 If the error is still present, replace the failing cartridge and print the Print Quality
Test Print again.
Test 4 (Color Alignment Quality) is in two parts:
The first of the patterns (in the upper line) tests alignment between the cyan and
magenta cartridges; it should be blue with no cyan or magenta shadows. The
second tests alignment between the cyan and yellow cartridges; it should be
green with no cyan or yellow shadows. The third tests alignment between the
magenta and yellow cartridges; it should be red, with no magenta or yellow
shadows.
Special internal prints
Using the Print Quality Test Print
