Printing area (= media size minus margins). For margins, see page 10–3.
Media size
Printing area (width x height)
by orientation of drawing
(and orientation
inches millimeters
of media )
landscape portrait landscape portrait
ANSI media A (portrait) 9.66 x 8.1 8.1 x 9.66 245 x 205 205 x 245
A (landscape) 10.6 x 7.16 7.16 x 10.6 269 x 182 182 x 269
B (portrait) 15.7 x 10.6 10.6 x 15.7 397 x 269 269 x 397
B (landscape) 16.6 x 9.66 9.66 x 16.6 421 x 245 245 x 421
C (portrait) 20.7 x 16.6 16.6 x 20.7 524 x 421 421 x 524
C (landscape) 20.6 x 15.7 15.7 x 20.6 549 x 398 398 x 549
D (portrait) 32.7 x 21.6 21.6 x 32.7 829 x 548 548 x 829
D (landscape) 33.6 x 20.7 20.7 x 33.6 854 x 525 525 x 854
E (portrait) 42.7 x 33.6 33.6 x 42.7 1084 x 854 854 x 1084
Architectural
di
A (portrait) 10.7 x 8.60 8.6 x 10.7 271 x 219 219 x 271
me
di
a
A (landscape) 11.6 x 7.66 7.66 x 11.6 295 x 195 195 x 295
B (portrait) 16.7 x 11.6 11.6 x 16.7 423 x 295 295 x 423
B (landscape) 17.6 x 10.7 10.7 x 17.6 447 x 271 271 x 447
C (portrait) 22.7 x 17.6 17.6 x 22.7 576 x 447 447 x 576
C (landscape) 23.6 x 16.7 16.7 x 23.6 600 x 423 423 x 600
D (portrait) 34.7 x 23.6 23.6 x 34.7 880 x 600 600 x 880
D (landscape) 35.6 x 22.7 22.7 x 35.6 904 x 576 576 x 904
E1 (portrait) 40.7 x 29.6 29.6 x 40.7 1033 x 752 752 x 1033
E (portrait) 46.7 x 35.6 35.6 x 46.7 1185 x 904 904 x 1185
ISO media A4 (portrait) 10.3 x 7.87 7.87 x 10.3 263 x 200 200 x 263
A4 (landscape) 11.3 x 6.93 6.93 x 11.3 287 x 176 176 x 287
A3 (portrait) 15.2 x 11.3 11.3 x 15.2 386 x 287 287 x 386
A3 (landscape) 16.1 x 10.3 10.3 x 16.1 410 x 263 263 x 410
A2 (portrait) 22.0 x 16.1 16.1 x 22.0 560 x 410 410 x 560
A2 (landscape) 23.0 x 15.2 15.2 x 23.0 584 x 386 386 x 584
A1 (portrait) 31.8 x 23.0 23.0 x 31.8 807 x 584 584 x 807
A1 (landscape) 32.7 x 22.0 22.0 x 32.7 831 x 560 560 x 831
A0 (portrait) 45.5 x 32.7 32.7 x 45.5 1155 x 831 831 x 1155
