HP Designjet 4500

7-2
Parts and Diagrams
HP Designjet 4500 Printer Series Service Manual
Printer Support
Printer Support
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1271-60670 2 Foot Assembly
2 Q1271-60672 2 Legs Assembly
3 Q1271-60675 1 X-Brace Assembly
4 Q1271-60457 1 Bin Assembly
- Q1271-60675 1
Hardware Kit (Includes screws for Legs
Assembly)
5 Q1271-60459 2 Leg Cover
