7-18
Parts and Diagrams
HP Designjet 4500 Printer Series Service Manual
Scan-Axis Assemblies
Scan-Axis Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60254 1 Ink Supply Tubes and Trailing Cable
2 Q1273-60228 1 Belt and Tensioner Assembly
3 Q1273-60071 1 Scan-Axis Motor
4 Q1273-60239 1 Encoder Strip and Encoder Sensor Kit
5 Q1273-60108 5 Ink Supply Tubes Clips
6 Q1273-60112 2 Rear Tube Brackets
