7-22
Parts and Diagrams
HP Designjet 4500 Printer Series Service Manual
Paper Path Assemblies
Paper Path Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1271-60644 1 Center Platen
2 Q1271-60622 1 Output Platen
3 Q1271-60623 2 Media Deflectors Kit
4 Q1271-60624 1 Media Deflector with Sensor
