7-26
Parts and Diagrams
HP Designjet 4500 Printer Series Service Manual
Rear Path Assembly
Rear Path Assembly
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1271-60611 1 Rear Path Assembly
2 Q1271-60640 1 Rear Path Cable Kit
3 Q1271-60649 1 Left & Right Cable Arm
4 Q1271-60636 1 Main Media Sensor
5 Q1271-60637 1 Single Sheet Loading Media Sensor
6 Q1271-60637 1 Roll 1 Media Sensor
7 Q1271-60637 1 Back Channel Sensor
8 Q1271-60732 1 Mylar Strip
