7-30
Parts and Diagrams
HP Designjet 4500 Printer Series Service Manual
Roll 1 Drawer Assembly
Roll 1 Drawer Assembly
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1271-60619 1 Right Spindle Support
2 Q1271-60620 1 Left Spindle Support
3 Q1271-60621 1 Drawer Guide and Bar
4 Q1271-60627 1 42" Spindle (does NOT include Blue Hub)
5 Q1271-60628 1 Blue Hub
6 Q1271-60650 1 Left and Right Drawer Sliders
7 Q1271-60641 1 Drawer Switch Sensor
8 Q1271-60699 1 Cutter
- Q1271-60629 1 3" Spindle Adaptors
