Input Trays
Input Trays
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1Q5677-600091Input Platen
2 Q5677-60005 1 Lower Input Platen
3 Q5677-60006 1 Right Printer Interlock
4 Q5677-60007 1 Left Printer Interlock
5 Q5677-60010 1 Deflectors
6Q5677-600081Buffer Sensor
