8-8
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
Right Cover
Removal
Switch off the product and remove the power cable.
1. Unclip the Quick reference Guide Holder
from the rear of the Printer.
2. Using a small flat-blade screwdriver, unclip
the Front Panel Bezel from the Right Cover.
3. Remove the Front Panel Bezel from the
Right Cover.
1
2
To Next Page
