8-48
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
6. Disconnect the two Ink Supply Station
cables from the PrintMech PCA.
7. Release the Ink Supply Station from the
Chassis.
8. Remove the Ink Supply Station from the
Printer.
1
2
