8-51
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
Middle Left Spittoons
Removal
Switch off the product and remove the power cable.
1. Open the Window.
2. Remove one T-10 screw (Type C) that
secures the Middle Left Spittoons.
3. Remove the Middle Left Spittoons from the
Printer.
After installing the NEW Middle Left
Spittoons, make sure you perform
the following Service Utility:
Reset life counter mid left spittoon
⇒
Chapter 4.
