8-94
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
Formatter Battery
Removal
Switch off the product and remove the power cable.
1. Remove the JetDirect Card (if installed).
2. Remove three T-15 screws (Type A) that
secure the Main PCA cover.
3. Remove the Main PCA Cover from the
Printer.
1
2
To Next Page
