8-173
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
4. Pull out the Roll 1 Module as far as it will
go.
5. Move the Roll 1 Paper Load Lever to the Up
position.
6. Remove three T-8 screws (Type L) that
secure a metal cover on the right side of
Roll 1 Module.
