HP Designjet 4500 - Page 504

8-204
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
12. Rotate the white Pinch Roller Arm Bushing
on the left side.
13. Remove the Pinch Roller Arm Assembly.
14. Remove two T20 screws (Type M) from
each Pinch Roller Assembly.
