HP Designjet 4500 - Page 536

8-236
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
23. Move the cables away from the rear of the
Printer.
24. Remove the cable clamp from inside the
rear of the Printer.
25. Remove one T-15 screw (Type F) that
secures the Drive Pinch Lever Linkage to the
Spring.
