HP Designjet 4500

8-243
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
4. Remove one screw that secures the Right
Cover from underneath at the rear.
5. Remove the LED from inside the Right
Cover.
Use a flat-ended screw driver to
prise apart the plastic holder
securing the LED to the inside of
the Right Cover.
6. Remove the Right Cover
