HP Designjet L25500 Series

8 Printer specifications
Functional specifications
Table 8-1 HP No. 789 ink supplies
Printheads Yellow/black, cyan/light cyan and light magenta/magenta
Printhead cleaning kit and printhead cleaning
container
Non-color-specific
Ink cartridges Yellow, black, magenta, light magenta, cyan and light cyan. All cartridges
contain 775 ml of ink.
Table 8-2 Substrate sizes
Minimum Maximum
Width 584 mm (23 in)
Narrow substrate: 254 mm (10 in)
1067 mm (42 in) or 1524 mm (60 in)
Length 420 mm (16.5 in) Roll with maximum external diameter of 180 mm
(7.1 in)
Table 8-3 Print resolutions
Ink level Number of passes Halftone resolutions (dpi) Print resolutions (dpi)
100% 4–28 (except 18) 300, 600 1200×1200
18 1200 1200×1200
200% 10–28 (except 18) 300, 600 1200×1200
18 1200 1200×1200
The table above shows the resolutions supported by the printer. See your RIP documentation to find
the resolutions supported by your RIP.
Table 8-4 Margins
Side margins 5 mm = 0.2 inches
Top margin (leading edge) 5 mm = 0.2 inches
Bottom margin (trailing edge) 5 mm = 0.2 inches (none)
100 mm = 3.9 inches (small)
150 mm = 5.9 inches (normal)
200 mm = 7.9 inches (Extra)
72 Chapter 8 Printer specifications ENWW
