HP Designjet T Series — Service Manual 3-51
Service Tests (Diagnostics)
7 The Front Panel prompts you to shutdown the printer to complete the test.
8 Press any key to shutdown the printer.
9 Recover the Printheads. See
Chapter 1 Image Quality Maintenance
Procedure on page 1-49.
12. Set Unit Configuration
This diagnostic test is not available.
13. Error 71:19 Recovery
This diagnostic test utility is used to set the Serial Number and Part Number
the case that:
The Formatter and Printmech PCA have been replaced at the same time
(T1100/T1100ps/T610).
The Formatter and Media Advance Encoder PCA have been replaced at
the same time (T1120/T1120ps).
The complete Error 71:19 Recovery utility consists of individual utilities to
handle differ
ent serial and part number setting requirements. These tests are:
Set Serial Number
Select Right S/N
Set Serial Number
1 In the Diagnostics menu, scroll to 1
3. Error 71:19 Recovery and press
OK.
