Removal and Installation
6-170 HP Designjet T Series — Service Manual
11. Remove the four T-15 screws that secure
the Ink Supply Tubes to the Carriage
Assembly.
12. Carefully lift out the Ink Supply Tubes and
close the carriage cover at the same time.
13. Close and lock the Carriage Cover.
To Next Page
