HP Designjet T2300 eMultifunction Printer series
Technical specifications
Print
Line Drawings
28 sec/page, 103 A1 prints per hour
Colour images
41 m²/hr on coated media; 6.7 m²/hr on glossy media
Print speed
51 m²/hr
Print resolution
Up to 2400 x 1200 optimised dpi from 1200 x 1200 input dpi and Optimisation For
Photo Paper selected
Margins (top x bottom x left x right)
Roll: 5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom); borderless on photo papers
Sheet: 5 mm (top), 5 mm (right), 5 mm (left), 17 mm (bottom)
Technology
HP Thermal Inkjet
Ink types
Dye-based (C, M, Y, G, pK); pigment-based (mK)
Ink colours
6 (cyan, grey, magenta, matte black, photo black, yellow)
Ink drop
6 pl (C, M, pK, G), 9 pl (Y, mK)
Print head nozzles
1056
Print heads
3 (matte black and yellow, magenta and cyan, photo black and grey)
Line accuracy
+/- 0.1%
Minimum line width
0.02 mm (HP-GL/2 addressable)
Guaranteed minimum line width
0.06 mm (ISO/IEC 13660:2001(E))
Maximum print length
91 m (application dependent)
Scan
Scan speed
Up to 3.81 cm/sec (colour, 200 dpi); up to 11.43 cm/sec (greyscale, 200 dpi)
Scan resolution, hardware
Up to 600 x 600 dpi
Scan resolution, optical
Up to 600 dpi
Scan size (flatbed), maximum
914 x 5000 mm (PDF); 914 x 7000 mm (TIFF)
Copy
Copy resolution
Up to 600 dpi
Copy reduce / enlarge settings
25 to 400%
Maximum number of copies
Up to 99 copies
Media
Handling
Printer: sheet feed, two automatic roll feeds, automatic roll-switching, automatic cutter;
scanner: straight-through scan paper path for sheet and cardboard originals
Types
Printer: bond and coated paper, technical paper, film, photographic paper, backlit,
self-adhesive; scanner: non-abrasive paper, vellum, translucent, opaque Mylar, recycled,
blueprints, cardboard (No plywood, stone plates, metal plates or abrasive, dirty, rough,
sharp edged, metal clamped, or burned surfaces or transparencies)
Weight
60 to 328 g/m²
Size
210 x 279 to 1118 x 1676 mm
Thickness
Up to 0.8 mm
Memory
Standard
32 GB
Hard disk
Standard, 160 GB
Connectivity
Interfaces (standard)
Gigabit Ethernet (1000Base-T); EIO Jetdirect accessory slot; Hi-Speed USB 2.0
Interfaces (optional)
Compatible HP Jetdirect LAN cards
Print languages (standard)
CN727A: TIFF, JPEG, HP-GL/2, HP-RTL, CALS G4, HP PCL 3 GUI; CN728A: Adobe
PostScript® 3, Adobe PDF 1.7, TIFF, JPEG, HP-GL/2, HP-RTL, CALS G4, HP PCL 3 GUI;
Operating systems compatibility
CN727A: Windows® 7 Ultimate/Professional/Home Premium; Windows Vista®
Ultimate/Business/Home Premium; Microsoft® Windows® XP (32-bit, 64-bit)
Professional/Home, Server 2008 (32-bit, 64-bit), Server 2003 (32-bit, 64-bit); Mac OS X
v10.4, v10.5, v10.6; Citrix® XenApp; Citrix® XenServer; CN728A: Windows® 7
Ultimate/Professional/Home Premium; Windows Vista® Ultimate/Business/Home
Premium; Microsoft® Windows® XP (32-bit, 64-bit) Professional/Home, Server 2008
(32-bit, 64-bit), Server 2003 (32-bit, 64-bit); Mac OS X v10.4, v10.5, v10.6; Citrix®
XenApp; Citrix® XenServer; Linux (see http://www.hplip.net);
Recommended system requirements
Mac
Mac OS X v10.4, v10.5: PowerPC G3 or Intel® Core processor, 256 MB RAM, 1 GB
available hard disk space; Mac OS X v10.6: Mac computer with Intel® Core processor, 1
GB RAM, 2 GB available hard disk space
Windows
Windows® 7: 32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM (32-bit) or 2 GB
RAM (64-bit), 2 GB available hard disk space; Windows Vista® Ultimate/Business/Home
Premium: 32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM; 2 GB available hard
disk space; Microsoft® Windows® XP Professional/Home (SP2 or higher): Intel®
Pentium® family or AMD K6™/Athlon™/Duron™ family (1 GHz), 512 MB RAM, 2 GB
available hard disk space
Environmental ranges
Operating temperature
5 to 40ºC
Storage temperature
-25 to 55ºC
Operating humidity
20 to 80% RH
Storage humidity
0 to 95% RH
Acoustic
Sound Pressure
43 dB(A)
Sound Power
6.1 B(A)
What's in the box
CN727A
HP Designjet T2300 eMultifunction Printer; printheads; introductory ink cartridges;
printer stand; spindle; quick reference guide; setup poster; startup software; Scan2CAD
software; USB cable; power cord
CN728A
HP Designjet T2300 PostScript eMultifunction Printer; printheads; introductory ink
cartridges; printer stand; spindle; quick reference guide; setup poster; startup software;
Scan2CAD software; USB cable; power cord
Dimensions (w x d x h)
Printer
1771 x 1010 x 1124 mm
Packaged
1930 x 766 x 827 mm
Weight
Printer
103 kg
Packaged
135 kg
Power consumption
Maximum
< 120 watts (active); < 41 watts (standby); < 11 watts / < 28 watts with embedded
Digital Front End (sleep); < 0.1 watts (manual-off)
Power requirements
Input voltage: 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz)
Certification
Safety
EU (LVD and EN 60950-1 compliant); Russia (GOST)
Electromagnetic
Compliance for Class B ITE products: EU (EMC Directive)
Environmental
ENERGY STAR®; WEEE; EU RoHS; China RoHS; REACH; FEMP
ENERGY STAR
Yes
Warranty
Standard warranty: two years, next business day on-site support. Warranty and
support options vary by product, country and local legal requirements.
Ordering information
Product
CN727A
HP Designjet T2300 eMultifunction Printer
CN728A
HP Designjet T2300 PostScript eMultifunction Printer
Accessories
Q6709A
HP Designjet 1118mm Roll Feed Spindle
Ink supplies
C9380A
HP 72 Gray and Photo Black Printhead
C9383A
HP 72 Magenta and Cyan Printhead
C9384A
HP 72 Matte Black and Yellow Printhead
C9397A
HP 72 69-ml Photo Black Ink Cartridge
C9398A
HP 72 69-ml Cyan Ink Cartridge
C9399A
HP 72 69-ml Magenta Ink Cartridge
C9400A
HP 72 69-ml Yellow Ink Cartridge
C9401A
HP 72 69-ml Grey Ink Cartridge
C9403A
HP 72 130-ml Matte Black Ink Cartridge
C9370A
HP 72 130-ml Photo Black Ink Cartridge
C9371A
HP 72 130-ml Cyan Ink Cartridge
C9372A
HP 72 130-ml Magenta Ink Cartridge
C9373A
HP 72 130-ml Yellow Ink Cartridge
C9374A
HP 72 130-ml Grey Ink Cartridge
CH575A
HP 726 300-ml Matte Black Designjet Ink Cartridge
Media supplies
C6030C
HP Heavyweight Coated Paper-914 mm x 30.5 m (36 in x 100 ft)
Q1397A
HP Universal Bond Paper-914 mm x 45.7 m (36 in x 150 ft)
Service & support
UX901E HP Care Pack, Next Business Day Designjet T2300eMFP Hardware Support, 3 years
UX908E HP Care Pack, Next Business Day Designjet T2300eMFP Hardware Support, 4 years
UX907E HP Care Pack, Next Business Day Designjet T2300eMFP Hardware Support, 5 years
UX902E HP Care Pack, 4 Hour Response Time 13x5 Designjet T2300eMFP Hardware Support, 3 years
UX915PE HP Care Pack, Post Warranty Next Business Day Designjet T2300eMFP Hardware Support, 1 year
UX914PE HP Care Pack, Post Warranty Next Business Day Designjet T2300eMFP Hardware Support, 2 years
UX917PE HP Care Pack, Post Warranty 4 Hour Response Time 13x5 Designjet T2300eMFP Hardware Support, 1 year
H4518E HP Care Pack, Network Install Designjet T23-71XX, 400-6200 SVC
Count on dependable support to create the best image possible. We can help you enhance your printing and
imaging environment, protect your IT investment, and grow your business—with expert support that’s affordable,
personal, and tailored to your needs through HP Care Pack Services.
For more information, please visit http://www.hp.com/go/designjetT2300eMFP
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
© Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
4AA2-6604EEE Published in EMEA June 2013
