HP Designjet T2300 Service Manual

Notices
Warranty
The information contained in this
document is subject to change without
notice.
Hewlett-Packard makes no
warranty of any kind with regard to
this material, including, but not
limited to, the implied warranties of
merchantability and fitness for a
particular purpose.
Hewlett-Packard shall not be liable for
errors contained herein or for
incidental or consequential damages
in connection with the furnishing,
performance, or use of this material.
WARNING
The procedures described in this manual are
to be performed by HP-qualified service
personnel only.
Electrical Shock Hazard
Serious shock hazard leading to death or
injury may result if you do not take the
following precautions:
●
Ensure that the ac power outlet (mains)
has a protective earth (ground)
terminal.
●
Disconnect the product from the power
source prior to performing any
maintenance.
●
Prevent water or any other liquids from
running onto electrical components or
circuits, or through openings in the
enclosure.
Electrostatic Discharge
Refer to the beginning of Chapter 4
Introduction on page 191 of this manual, for
precautions you should take to prevent
damage to the product circuits from
electrostatic discharge.
Safety Symbols
General definitions of safety symbols are
given immediately after the table of contents.
WARNING
The Warning symbol calls attention to a
procedure, practice, or the like, which,
if not correctly performed or adhered to,
could result in personal injury. Do not
proceed beyond a Warning symbol until
the indicated conditions are fully
understood and met.
CAUTION
The Caution symbol calls attention to
an operating procedure, practice, or the
like, which, if not correctly performed or
adhered to, could result in damage to or
destruction of part or all of the product.
Do not proceed beyond a Caution
symbol until the indicated conditions
are fully understood and met.
Content Management Department,
Barcelona Division,
Hewlett-Packard Espanola, S.A.
Avda. Graells, 501
08190 Sant Cugat del Valles
Spain
ENWW iii

HP Designjet T2300 Specifications

General

Coated paper	Yes
Maximum scan size	914 x 2378 mm
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Printing colors	Cyan, Magenta, Matte black, Photo black, Yellow
Maximum resolution	2400 x 1200 DPI
Print head nozzles	1056
Number of print cartridges	6
Storage media	HDD
Built-in processor	Intel® Pentium® M
Internal storage capacity	160 GB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Scan file formats	TIFF
Hardware scan resolution	600 x 600 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Sustainability certificates	ENERGY STAR
Package weight	135 g
Media thickness	0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	91 m m
Maximum roll diameter	135 mm
Recommended media weight	60 - 328 g/m²
ISO A-series sizes (A0...A9)	A0, A1, A2, A3, A4
Power consumption (standby)	41 W
Power consumption (typical)	120 W

Weight and Dimensions

Dimensions (WxDxH)	1771 x 1010 x 1124 mm
