HP Designjet T2300 Service Manual

Using this Manual
Purpose
This Service Manual contains information necessary to test, calibrate and service:
●
HP Designjet T2300 eMFP 44 inch (Model CN727A)
●
HP Designjet T2300 eMFPps 44 inch (Model CN728A)
For information about using these products, refer to the corresponding User and Quick Reference
Guides.
Readership
The procedures described in this Service Manual are to be performed by HP Certified service personnel
only.
Part Numbers
Part Numbers for product service parts are located in Chapter 7
Parts and Diagrams on page 169.
ENWW v

HP Designjet T2300 Specifications

General

Coated paper	Yes
Maximum scan size	914 x 2378 mm
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Printing colors	Cyan, Magenta, Matte black, Photo black, Yellow
Maximum resolution	2400 x 1200 DPI
Print head nozzles	1056
Number of print cartridges	6
Storage media	HDD
Built-in processor	Intel® Pentium® M
Internal storage capacity	160 GB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Scan file formats	TIFF
Hardware scan resolution	600 x 600 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Sustainability certificates	ENERGY STAR
Package weight	135 g
Media thickness	0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	91 m m
Maximum roll diameter	135 mm
Recommended media weight	60 - 328 g/m²
ISO A-series sizes (A0...A9)	A0, A1, A2, A3, A4
Power consumption (standby)	41 W
Power consumption (typical)	120 W

Weight and Dimensions

Dimensions (WxDxH)	1771 x 1010 x 1124 mm
