10. Remove the Top Cover with the Front Cover.
Lower Front Cover
Removal
1. Remove the Right Cover
Right Cover on page 416.
2. Remove the Left Cover
Left Cover on page 418.
3. Remove the Drive Motor
Drive Motor on page 428.
4. Remove six screws that secure the top of the Electronics Module to the chassis.
422 Chapter 10 Stacker part removal and installation ENWW
