HP DESIGNJET T7100 Monochrome Series

4. Loosen one screw on the right side of the Pinchwheel.
5. Rotate the bottom of the Pinchwheel slightly.
6. Remove the Pinchwheel.
Drive Motor
Removal
1. Remove the Right Cover
Right Cover on page 416.
428 Chapter 10 Stacker part removal and installation ENWW
