Hardware options installation 66
6.
Attach the cable to the cache module.
7. Install the battery.
8. Connect the cable to the battery.
The SPI board is not shown for clarity.
9. Install the access panel.
10. Slide the server back into the rack.
11. Power up the server (on page 25, "Powering up and configuring the server" on page 34).
FBWC module and capacitor pack option
CAUTION: Do not use this controller with cache modules designed for other controller
models, because the controller can malfunction and you can lose data. Also, do not transfer
this cache module to a different controller module, because you can lose data.
