Reverse this procedure to install the card reader board, cable, and bracket.
Speaker
Description Spare part number
Speaker 598799-001
Before removing the speaker, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48), and then remove the following components:
a. Memory module compartment cover (see
Expansion memory module on page 52)
b. Wireless module compartment cover (see
WLAN module on page 57)
c. Switch cover and keyboard (see
Switch cover and keyboard on page 69)
d. Display assembly (see
Display assembly on page 76)
e. Top cover (see
Top cover on page 85)
Remove the speaker:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the Phillips PM2.0×4.0 screw (2) and the Phillips PM2.0×6.0 screw (3) that secure the
speaker to the base enclosure.
ENWW Component replacement procedures 91
