HP EliteBook 2740p Maintenance And Service Guide

Cables and connectors
CAUTION: When servicing the computer, be sure that cables are placed in their proper locations
during the reassembly process. Improper cable placement can damage the computer.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to
unseat or seat the cables during removal and insertion. Handle cables by the connector whenever
possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in
such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex
cables with extreme care; these cables tear easily.
Drive handling
CAUTION: Drives are fragile components that must be handled with care. To prevent damage to
the computer, damage to a drive, or loss of information, observe these precautions:
Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the
computer is off or in Hibernation, turn the computer on, and then shut it down through the operating
system.
Before handling a drive, be sure that you are discharged of static electricity. While handling a drive,
avoid touching the connector.
Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and
be sure that the optical drive tray is closed.
Handle drives on surfaces covered with at least one inch of shock-proof foam.
Avoid dropping drives from any height onto any surface.
Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.
Avoid exposing a drive to temperature extremes or liquids.
If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”
32 Chapter 4 Removal and replacement procedures ENWW

HP EliteBook 2740p Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor technology	Intel Centrino 2 w/ vPro
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.07 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	19
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Display	-
Modem speed	56 Kbit/s
Battery type	HP Long Life 6-cell (39 WHr) Lithium-Ion Primary Battery
Graphics card	HD Graphics
Internal modem	Yes
Expansion slots	1 Express Card/34; 1 Smart Card Reader; 1 secure digital/MultiMedia card
Video card note	Microsoft DirectX 10 (Shader 4.0) and OpenGL 2.1 capable, with DDR3 system memory
Dimensions (WxDxH)	290 x 212 x 31.7 mm
Power requirements	External 65W Smart AC adapter; Power cord (1.8 meters, with AC adapter 3.66 meters); HP Fast Charge
HDD controller type	Solid State Drive SATA II (5400 rpm)
Wireless technology	Intel 802.11a/b/g; HP Integrated Module with Bluetooth 2.1 Wireless Technology
Maximum HDD capacity	320 GB
Intel segment tagging	Enterprise
Minimum storage drive space	160 GB
Compatible operating systems	Genuine Windows Vista Enterprise 32; Genuine Windows Vista Enterprise 64; Genuine Windows 7 Home Premium; SuSE Linux Enterprise 10
Main camera resolution (numeric)	2 MP
Bluetooth version	2.1+EDR
Networking features	Integrated Intel 82577 Gigabit Ethernet (10/100/1000 NIC)
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Memory slots	2x SO-DIMM
Memory upgrade	8 GB
Internal memory	4 GB
Memory clock speed	1333 MHz
HDD capacity	0 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Audio system	HD
Audio included	High Definition Audio support with 24-bit DAC, Integrated stereo speakers, Integrated dual-microphone array, Touch-sensitive controls for volume up, volume down, and mute, Combo headphone/mic jack
Motherboard chipset	Intel® QM57 Express
I/O ports	3 USB 2.0; 1 1394a; 1 AC power; 1 combo stereo headphone/mic jack; 1 docking connector; 1 RJ-11; 1 RJ-45; 1 secondary battery connector; 1 VGA-in
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	1
Number of battery cells	6
Trial software	WinZip 12; Microsoft Office Professional 2007; HP SkyRoom
Bundled software	HP Recovery Manager; HP Support Assistant; HP QuickLaunch Buttons; HP QuickLook 3; HP QuickWeb; HP DayStarter; HP Power Assistant; HP Connection Manager; HP Wireless Assistant
Operating system installed	Windows 7 Professional
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Country of origin	China
Storage drive type	160 GB Solid State Drive SATA II Hard Drive 160, 250 or 320 GB (5400 rpm), Solid State Drive 80 or 160 GB, HP 3D DriveGuard
Keyboard type	HP spill-resistant keyboard, HP Night Light shines directly on the keyboard for low-light conditions
Keyboard layout	QWERTY
Processor ARK ID	43544
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz

Weight and Dimensions

Depth	212 mm
Width	290 mm
Height	31.7 mm
Weight	1720 g
