HP EliteBook 2740p - Capturing Business Card Images

●
Modem module (see
Modem module on page 67)
●
Heat sink (see
Fan/heat sink assembly on page 73)
Remove the system board:
1. Position the computer right-side up, with the front toward you.
2. Remove the ExpressCard or ExpressCard slot holder.
3. Disconnect the audio connector board cable (1) and the Bluetooth module cable (2) from the
system board.
ENWW Component replacement procedures 71
