HP EliteBook 2760p User Manual

Item Description Spare part number
For use in Taiwan 649756-AB1
For use in Thailand 649756-281
For use in Turkey 649756-141
For use in the United Kingdom 649756-031
For use in the United States 649756-001
(5) Memory modules (PC3-10600, 1333-MHz, DDR3)
8-GB 634091-001
4-GB 621569-001
2-GB 621565-001
1-GB 639738-001
(6) Top cover assembly (includes TouchPad board, QuickWeb button, and capacitive board) 649768-001
(7) TouchPad button board (included with the top cover assembly 649768-001)
(8) TouchPad button board bracket (included with the top cover assembly 649768-001)
(9) RTC battery 649769-001
(10) Speaker assembly 649767-001
(11) System board shield (includes replacement thermal material) 649760-001
(12) Fan/heat sink assembly (includes replacement thermal material) 649759-001
(13) Security lock
(14) Modem module 56k, v.92 MDC 1.5 Guzzi F data/fax, for use in all countries
NOTE: The modem module spare part kit does not include a modem module cable. The
modem module cable is included in the Cable Kit, spare part number 649758-001. See
Cable Kit on page 24 for more Cable Kit spare part number information.
628824-001
(15) Smart card reader 597839-001
(16) System board (includes replacement thermal material)
For use in all countries and regions except Russia and the People's Republic of China:
●
Equipped with Second Generation Intel Core i5-2410M Dual-Core processor [2.3 GHz
(turbo up to 2.9 GHz), 3 MB L3 cache]
649745-001
●
Equipped with Second Generation Intel Core i5-2520M Dual-Core processor [2.5 GHz
(turbo up to 3.2 GHz), 3 MB L3 cache]
649746-001
●
Equipped with Second Generation Intel Core i5 2540M Dual-Core processor [2.6 GHz
(turbo up to 3.3 GHz), 3 MB L3 cache]
649747-001
●
Equipped with Second Generation Intel Core i7-2620M Dual-Core processor [2.7 GHz
(turbo up to 3.4 GHz), 4 MB L3 cache]
649748-001
For use only in Russia and the People's Republic of China:
●
Equipped with Second Generation Intel Core i5-2410M Dual-Core processor [2.3 GHz
(turbo up to 2.9 GHz), 3 MB L3 cache]
649749-001
●
Equipped with Second Generation Intel Core i5-2520M Dual-Core processor [2.5 GHz
(turbo up to 3.2 GHz), 3 MB L3 cache]
649750-001
20 Chapter 3 Illustrated parts catalog

HP EliteBook 2760p Specifications

General

HDD capacity	- GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	128 GB
Compatible memory cards	MMC, SD
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	16 GB
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Graphics card	HD Graphics 3000
Graphics card family	Intel
Intel segment tagging	Enterprise
Minimum storage drive space	250 GB
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Bus type	DMI
Stepping	J1
Tjunction	100 C °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2500 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	26
Maximum number of PCI Express lanes	16
Audio system	SRS Premium Sound
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
HDMI ports quantity	-
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	1
Battery life (max)	5.5 h
Number of battery cells	6
Cable lock slot type	Kensington
Keyboard layout	QWERTY
Pointing device	Touchpad
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Country of origin	China
Processor code	SR046
Processor ARK ID	50072
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
On-board graphics card ID	0x116
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz

Weight and Dimensions

Depth	212 mm
Width	290 mm
Height	32.3 mm
Weight	1800 g
