8. Remove the two Phillips M2.5x7.0 screws (5).
9. Lift the rear edge (1) of the top cover.
10. Disengage the top cover from the computer, and then lift the top cover (2) up and off the
computer.
NOTE: A small plastic brace for the VGA port rests below the top cover. Simply lift the brace.
Component replacement procedures 59
