Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display assembly (non-touch)
IMPORTANT: All display assemblies are available as spare parts at the subcomponent
level only. For more display assembly spare part information,Display assembly
subcomponents on page 23.
not available as a whole
assembly
(2) Display assembly (touch) not available as a whole
assembly
(3) Keyboard (see Keyboard on page 41):
For a list of keyboard country codes, see Keyboard on page 41.
Without a backlight L13698-xx1
With a backlight L13697-xx1
With a backlight, privacy L15500-xx1
(4) Power button board L60628-001
(5) Top cover (includes power button) L62281-001
(6) Touchpad button board L19426-001
(7) Touchpad:
Without NFC antenna L60597-001
With NFC antenna L60598-001
(8) RTC battery L13694-001
(9) Fingerprint reader assembly (includes EMI gasket) L60625-001
(10) Smart card reader board L60626-001
(11) NFC module (includes antenna cable and foam) L64720-001
(12) Speakers (includes cable) L13684-001
(13) System board (includes processor and replacement thermal material, see System board on page 59):
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
AMD Ryzen 7 PRO 3700U processor L62284-xx1
AMD Ryzen 5 PRO 3500U processor L62283-xx1
AMD Ryzen 3 PRO 3300U processor L62282-xx1
(14) Memory module (DDR-2666):
4 GB L10598-850
8 GB 937236-850
16 GB 937438-850
(15) WLAN/Bluetooth combo card:
Realtek RTL8822BE 802.11ac 2 × 2 Wi-Fi + Bluetooth 4.2 Combo Adapter 915623-001
Computer major components 21
