Item Component Spare part number
FHD, non-touch, 250 nits L60603-001
FHD, non-touch, for use in models with an IR camera and ambient light sensor, 400 nits L60609-001
FHD, touch-on panel (TOP), 250 nits L60610-001
FHD, non-touch, privacy, 1000 nits L60613-001
Camera module (includes microphone):
(3) IR camera L60621-001
(4) HD camera L60622-001
Microphone module (not shown) L60630-001
Camera cables: L60602-001 (Cable Kit)
(5) HD camera
(6) IR camera
(7) Hinges (left and right) L13683-001 (Hinge Kit)
(8) WLAN antenna (included with display enclosure or available as a separate part) not available as a spare part
(9) WWAN antenna (included with display enclosure or available as a separate part in the
Antenna Kit)
not available as a spare part
(10) Display cable L60602-001 (Cable Kit)
(11) Hinge cover L13683-001 (Hinge Kit)
(12) Display enclosure (includes hinges, antennas, gasket, foam, and tape) L60615-001
Ambient light sensor board (includes foil shield; not illustrated) L60629-001
Camera privacy cover (not illustrated) L60631-001 (Plastics Kit)
24 Chapter 3 Illustrated parts catalog
